This model was tested in Cura 3.4.1 and printed on an Ultimaker 2 in PLA material. Below you can find printing recommendations for Cura, Simplify3D and Slic3r softwares.

Cura printing recommendations:

Recommendations: For all parts of Locks you need to change "Brim" type to "Skirt" in Build Plate Adhesion section.

To avoid printing problems, we recommend the following settings:

Quality

Layer Height: 0.1 mm

Initial Layer Height: 0.3 mm

Line Width: 0.4 mm

 Wall Line Width: 0.4 mm

  Outer Wall Line Width: 0.4 mm

  Inner Wall(s) Line Width: 0.4 mm

 Top/Bottom Line Width: 0.4 mm

 Infill Line Width: 0.4 mm

 Skirt/Brim Line Width: 0.4 mm

Support Line Width: 0.4 mm

 Initial Layer Line Width: 100%

Shell

Wall Thickness: 0.8 mm

  Wall Line Count: 2

Outer Wall Wipe Distance: 0.2 mm

Top Surface Skin Layers: 0

Top/Bottom Thickness: 0.8 mm

  Top Thickness: 0.8 mm

   Top Layers: 8

  Bottom Thickness: 0.8 mm

   Bottom Layers: 8

Top/Bottom Pattern: Lines

Bottom Pattern Initial Layer: Lines

Top/Bottom Line Directions: [ ]

Outer Wall Inset: 0 mm

Compensate Wall Overlaps: Check

  Compensate Outer Wall Overlaps: Check

  Compensate Inner Wall Overlaps: Check

Fill Gaps Between Walls: Everywhere

Filter Out Tiny Gaps: Check

Horizontal Expansion: 0 mm

Initial Layer Horizontal Expansion: 0 mm

Z Seam Alignment: Sharpest Corner

Seam Corner Preference: Hide Seam

Ignore Small Z Gaps: Check

Extra Skin Wall Count: 1

Infill

Infill Density: 20%

Infill Line Distance: 4.0 mm

Infill Pattern: Grid

Infill Line Directions: [ ]

Infill X Offset: 0 mm

Infill Y Offset: 0 mm

Infill Overlap Percentage: 10%

  Infill Overlap: 0.04 mm

Skin Overlap Percentage: 5%

  Skin Overlap: 0.02 mm

Infill Wipe Distance: 0.1 mm

Infill Layer Thickness: 0.1 mm

Gradual Infill Steps: 1

Gradual Infill Steps Height: 1.5 mm

Infill Before Walls: Check

Minimum Infill Area: 0 mm2

Skin Removal Width: 0.8 mm

  Top Skin Removal Width: 0.8 mm

  Bottom Skin Removal Width: 0.8 mm

Skin Expand Distance: 0.8

  Top Skin Expand Distance: 0.8

  Bottom Skin Expand Distance: 0.8

Maximum Skin Angle for Expansion: 90˚

  Minimum Skin Width for Expansion: 0.0

Material

Initial Layer Flow: 100%

Enable Retraction: Check

Retraction Extra Prime Amount: 0 mm3

Retraction Minimum Travel: 0.8 mm

Maximum Retraction Count: 90

Minimum Extrusion Distance Window: 6.5 mm

Nozzle Switch Retraction Distance: 16 mm

Nozzle Switch Retraction Speed: 20 mm/s

  Nozzle Switch Retract Speed: 20 mm/s

  Nozzle Switch Prime Speed: 20 mm/s

Speed

Print Speed: 45 mm/s

  Infill Speed: 45 mm/s

  Wall Speed: 22.5 mm/s

   Outer Wall Speed: 22.5 mm/s

   Inner Wall Speed: 45 mm/s

  Top/Bottom Speed: 15 mm/s

  Support Speed: 45 mm/s

   Support Infill Speed: 45 mm/s

Travel Speed: 45 mm/s

Initial Layer Speed: 22.5 mm/s

 Initial Layer Print Speed: 22.5 mm/s

 Initial Layer Travel Speed: 30 mm/s

Skirt/Brim Speed: 45 mm/s

Maximum Z Speed: 0 mm/s

Number of Slower Layers: 2

Travel

Combing Mode: All

Avoid Printed Parts when Traveling: Check

Travel Avoid Distance: 0.6562 mm

Layer Start X: 0.0 mm

Layer Start Y: 0.0 mm

Cooling

Enable Print Cooling: Check

Fan Speed: 100%

  Regular Fan Speed: 100%

  Maximum Fan Speed: 100%

Regular/Maximum Fan Speed Threshold: 10 s

Initial Fan Speed: 0%

Regular Fan Speed at Height: 0.3 mm

  Regular Fan Speed at Layer: 2

Minimum Layer Time: 5 s

Minimum Speed: 10 mm/s

Support

Generate Support: Check

Support Placement: Everywhere

Support Overhang Angle: 60°

Support Pattern: Zig Zag

Connect Support ZigZags: Check

Support Density: 15 %

  Support Line Distance: 2.5 mm

Support Z Distance: 0.15 mm

  Support Top Distance: 0.15 mm

  Support Bottom Distance: 0.15 mm

Support X/Y Distance: 1 mm

Support Distance Priority: Z overrides X/Y

Minimum Support X/Y Distance: 0.25 mm

Support Stair Step Height: 0.3 mm

Support Stair Step Maximum Width: 5.0 mm

Support Join Distance: 2.0 mm

Support Horizontal Expansion: 0.2 mm

Support Infill Layer Thickness: 0.1 mm

Gradual Support Infill Steps: 0

Use Towers: Check

Tower Diameter: 3.0 mm

Minimum Diameter: 3.0 mm

Tower Roof Angle: 65°

Build Plate Adhesion

Build Plate Adhesion Type: Brim (for all parts of locks use "Skirt")

Skirt/Brim Minimum Length: 250 mm

Brim Width: 8.0 mm

  Brim Line Count: 15

Brim Only on Outside: Check

Mesh Fixes

Union Overlapping Volumes: Check

Merged Meshes Overlap: 0.15 mm

Special Modes

Print Sequence: All at Once

Surface Mode: Normal

Experimental

Slicing Tolerance: Middle

Maximum Resolution: 0.01 mm

Flow rate compensation max extrusion offset: 0 mm

Flow rate compensation factor: 100%

Disclaimer: This model will look outstanding if printed on SLA/SLS 3D printer. The accuracy of the model printed on FFF printer can vary from the result shown in the pictures.
